The compact heavy duty pressure transmitter Danfoss MBS 3050 is designed for use in hydraulic applications with severe medium influences like cavitation, liquid hammer or pressure peaks and offers a reliable pressure measurement, even under harsh environmental conditions.The flexible pressure transmitter programme covers a 4-20 mA output signal, absolute and gauge (relative) versions.
Measuring ranges from 0-1 to 0-600 bar and a wide range of pressure- and electrical connections.Excellent vibration stability, robust construction, and a high degree of EMC/EMI protection equip the pressure transmitter to meet the most stringent industrial requirements.
Applications
It is used in hydraulic applications with severe medium influences like cavitation, industrial, Machinery, Ship building Etc.
Special Features
Designed for use in severe industrial and hydraulic environments
Enslosure and wetted parts of acid-resistant stainless steel (AISI 316L)
Pressure ranges in relative (gauge) or absolute from 0 up to 600 bar
All standard output signals: 4 – 20 mA, 0 – 5 V, 1 – 5 V, 1 – 6 V, 0 – 10 V, 1 – 10 V
A wide range of pressure and electrical connections
Temperature compensated and laser calibrated
For use in zone 2 explosive atmospheres
Note: For more detailed specifications, please download the additonal documents
